Features |
||
| Chassis | Leather Feel Coating |
| Number of Fans | 2 Fans |
| Fan Color | Blue |
| Case Fan Controller | 3 connecters |
| M/B Connecter | 20 pins + 4 pins ATX12V |
| SATA Connector | 2 built in |
| AGP Power Lead Technology | No |
| UV Reflective Cable Wrap | Yes |
| Top Silent Technology | 23Dba @ 60% Load |
| Over Voltage Protection | Yes |
| Over Current Protection | Yes |
| Short Circuit Protection | Yes |
| Certification | UL, CE, CB, FCC |
| Technical Specification | |
| AC Input |
100-120VAC or 200-240VAC |
|||||
| Current |
10/6A |
|||||
| Frequency |
60/50Hz |
|||||
| DC Output | 3.3V | +5V | +12V | -12V | -5V | +5VSB |
| Max Output Current | 26A | 45A | 28A | 1.0A | 0.8A | 2.5A |
| Combined Wattage |
220W |
336W | 12W | 4W | 12.5W | |
| Total Wattage | 430W | 22W | ||||
|
450W |
||||||
| Dimensions (W x H x D) |
6" x 3.5" x6.25" |
|||||
| Weight |
5 lbs |
|||||
