Xmicro EP-350FX

¡@

 The unique dual fan 350W Micro ATX is a Prescott ready power supply. This high power m ATX has the new sliding sockets which allow it to pair up with many mother boards such as P4, LGA socket 775 boards. There is no cables need for pin conversion and no voltage drop due to 20 to 24 pin change. Also, less cabling problem inside the chassis make it easy for system installation. And with 22A power from +12V rail the EP-350FX is able to support high-end VGA card in m ATX system!

Product Flyer Download



¡@
¡@
¡@
Features
Chassis Glossy Titanium Reflective
Number of Fans 2 Fans
M/B Connecter 20+4 Sliding Connector (Patented)
SATA Connector 2 build in
Noise Control Silent Technology
Over Voltage Protection Yes
Over Current Protection Yes
Short Circuit Protection Yes
Test HI-POT
Certification UL, CE, CB, FCC
Technical Specification
AC Input

                           100-240VAC

Current

                            6/3A

Frequency

                         60/50Hz

DC Output +3.3V +5V +12V1 +12V2 -12V -5V +5VSB
Max Output Current 18A 24A 18A 18A 0.3A 0.3A 2A
Combined Wattage

335W

15W
Total Wattage                  350W
Load Redulation                    +4%
Peak Load                  400W
Dimensions                               (W x H x D)

4.725' x 2.5' x5.275'

(12.5cm X 6.5cm X 13.5cm)

Weight

                3 lbs
