TG-380


Features
380W ATX 1.3V power supply
Black Metal Chassis
Individual Serial ATA lead
Tagan Silent Control Technology (TSCT)  22dBA at 60% load
Special Grounding Wire
Protected switch button
Push & Pull Dual Fan Design for High Thermal Solution
12V/22A provide power for more peripheral devices
Short Circuit Protection, Short Circuit Protection
Over Voltage Protection, Over Current Protection
UL, CE, CB, FCC  certified
100% HI-POT tested
Specifications
Model Name    TG-380
Dimension    160mm (L) x 150mm (W) x 86mm (H)
Weight    5Lb
MB Connecter     ATX 20pin + 4
SATA Connector     2
AC Input   115-230Vac
Current (AMP)    10/6A
Frequency (Hz)    47/63Hz
DC Output

 +3.3V

 +5V +12V -12V -5V +5VSB
Max Output Current   28A 37A 22A 1.0A 0.8A 2.5A
Combined Wattage   220W 264W 12W 4W 12.5W

 360W

 28W
Total Wattage

380W
